EJ-6000W Extreme-Power Battery Charger
Extreme-power 6000W charger for lead-acid and lithium batteries. Engineered for large commercial fleets, industrial complexes and charging infrastructure with IP54 protection and extreme temperature tolerance.
Input Voltage
AC 90-264V
Protection Level
IP54
Working Temp
-40°C ~ +60°C
Max Power
EJ-6000W
Technical Specifications
General Parameters
| AC Input Voltage | AC 90-264V |
| AC Input Current | ≤32A |
| Frequency Range | 40~70Hz |
| Power Factor | ≥0.98 |
| Efficiency | ≥93% |
| Working Temperature | -40°C ~ +60°C |
| Protection Level | IP54 |
| Charging Mode | Adjustable Dynamic Curve |
| CAN Communication | Optional |
| LED Indicator | Standard |
| Dimensions | 345×285×140mm |
Output Voltage Options
| Voltage | Max Current |
|---|---|
| 12V | 140A |
| 24V | 140A |
| 36V | 120A |
| 48V | 100A |
| 60V | 80A |
| 72V | 65A |
Key Features
Extreme Power Output
6000W output for massive commercial and industrial operations.
Ultra-Wide Voltage Range
Supports 12V to 72V for comprehensive applications.
IP54 Protection
Sealed design for demanding industrial environments.
Extreme Temperature
Operates reliably from -40°C to +60°C.
Dual Battery Chemistry
Charges both lead-acid and lithium batteries.
Enterprise Efficiency
93% efficiency for cost-effective large-scale operations.
Applications
The EJ-6000W is engineered for lead-acid and lithium battery charging in commercial and industrial applications.
Large Commercial Fleets
Enterprise vehicle operations
Industrial Complexes
Multi-facility charging infrastructure
Charging Infrastructure
Commercial charging stations
Physical Logistics
Large-scale logistics operations
Optional Connectors
AC Input Connectors
Supports all standard international plugs:
- Euro plug
- US plug
- UK plug
- AU plug
- Custom plugs available
DC Output Connectors
Multiple connector options available:
Frequently Asked Questions
Can the EJ-6000W charge both lead-acid and lithium batteries?
Yes, the EJ-6000W can be configured for both battery types with adjustable charging curves. Please specify your battery chemistry when ordering.
What is the charging time?
Charging time depends on battery capacity. Contact our team for specific estimates based on your battery specifications.
Is CAN communication available?
CAN communication is optional. If you need CAN bus integration for monitoring systems, please request this feature during ordering.
How does it perform in extreme conditions?
The EJ-6000W is engineered for extreme environments with IP54 protection and -40°C ~ +60°C temperature tolerance for mission-critical reliability.
Can the charger be customized?
Yes! OneE Charger offers custom solutions including CAN communication, specific voltage/current configurations, and custom connectors. Contact us to discuss your requirements.
Ready to Get Started?
Contact our team to request a quote, discuss your specific requirements, or learn more about the EJ-6000W charger.
Contact Us Today
